Ordering information
I/O relay terminal
|
Terminals
|
Type
|
Points
|
Internal I/O circuit common
|
Rated voltage
|
Order code
|
|
Push-in plus technology
|
Input
|
16
|
NPN (- common)
|
24 VDC
|
G70V-SID16P
|
|
PNP (+ common)
|
G70V-SID16P-1
|
|
Output
|
NPN (+ common)
|
G70V-SOC16P
|
|
PNP (- common)
|
G70V-SOC16P-1
|
Relay terminal sockets
|
Applicable I/O Relay Terminal
|
Type
|
Common Processing in Connector
|
Order code
|
|
G70V-SID16P
|
Input
|
NPN (- common)
|
G70V-ZID16P
|
|
G70V-SID16P-1
|
PNP (+ common)
|
G70V-ZID16P-1
|
|
G70V-SOC16P
|
Output
|
NPN (+ common)
|
G70V-ZOM16P
|
|
G70V-SOC16P-1
|
PNP (- common)
|
G70V-ZOM16P-1
|
Note: Relays are not mounted to the G70V-ZID/ZOM16P(-1) Relay Terminal Sockets. Combine the Relay Terminal Sockets with Slim I/O Relays or Slim I/O SSRs.
Accessories
Mountable Relays
|
Applicable I/O Relay Terminal
|
Type
|
Classification
|
Order code
|
|
G70V-SID16P(-1)
|
Input
|
Slim I/O Relays
|
G2RV-1-S-AP-G DC21
|
|
G70V-SOC16P(-1)
|
Output
|
Slim I/O Relays
|
No Latching Lever
|
G2RV-1-S-G DC21
|
|
Latching Lever
|
G2RV-1-SI-G DC21
|
|
Slim I/O SSRs
|
For AC
|
Zero cross function
|
G3RV-202S DC24
|
|
No zero cross function
|
G3RV-202SL DC24
|
|
For DC
|
G3RV-D03SL DC24
|
Note: Note: To use Slim I/O SSRs, either remove the Slim I/O Relays to mount them or order a Relay Terminal Socket and I/O SSRs separately and combine them.
When ordering, designate the rated voltage.
Labels
|
Minimum order (sheet) (quantity per sheet)
|
Order code
|
|
5 (1 sheet/72 pieces)
|
XW5Z-P2.5LB2
|
Parts for DIN Track Mounting
|
Type
|
Minimum order (quantity)
|
Order code
|
|
DIN Tracks
|
1 m
|
–
|
PFP-100N
|
|
0.5 m
|
PFP-50N
|
|
End Plate
|
10
|
PFP-M
|
|
Spacer
|
PFP-S
|
Refer to your OMRON website for details on the PFP- ⬜ .
Applicable cables
|
Name
|
Appearance
|
Cable length L (mm)
|
Applicable connectors
|
Order code
|
|
Cables with Loose Wires and Crimp Terminals
XW2Z-RY_C
|
16 I/O points
|
|
1,000
|
Various devices
|
XW2Z-RY100C
|
|
1,500
|
XW2Z-RY150C
|
|
2,000
|
XW2Z-RY200C
|
|
3,000
|
XW2Z-RY300C
|
|
5,000
|
XW2Z-RY500C
|
|
Cables with Loose Wires
XW2Z-RA_C
|
16 I/O points
|
|
2,000
|
Various devices
|
XW2Z-RA200C
|
|
5,000
|
XW2Z-RA500C
|
|
Cables with Connectors (1:1)
XW2Z-R_C
|
16 I/O points
|
|
500
|
PLC I/O Units with
Fujitsu connectors (1:1)
|
XW2Z-R50C
|
|
1,000
|
XW2Z-R100C
|
|
1,500
|
XW2Z-R150C
|
|
2,000
|
XW2Z-R200C
|
|
3,000
|
XW2Z-R300C
|
|
5,000
|
XW2Z-R500C
|
|
Cables with Connectors (1:2)
XW2Z-RI_C-_,
XW2Z-RO_C-_
|
32 input points
|
|
(A) 1,000
|
(B) 750
|
PLC I/O Units with
Fujitsu connectors (1:2)
|
XW2Z-RI100C-75
|
|
(A) 1,500
|
(B) 1,000
|
XW2Z-RI150C-100
|
|
(A) 1,500
|
(B) 1,250
|
XW2Z-RI150C-125
|
|
(A) 2,000
|
(B) 1,750
|
XW2Z-RI200C-175
|
|
(A) 3,000
|
(B) 2,750
|
XW2Z-RI300C-275
|
|
(A) 5,000
|
(B) 4,750
|
XW2Z-RI500C-475
|
|
32 output points
|
(A) 1,000
|
(B) 750
|
XW2Z-RO100C-75
|
|
(A) 1,500
|
(B) 1,000
|
XW2Z-RO150C-100
|
|
(A) 1,500
|
(B) 1,250
|
XW2Z-RO150C-125
|
|
(A) 2,000
|
(B) 1,500
|
XW2Z-RO200C-150
|
|
(A) 2,000
|
(B) 1,750
|
XW2Z-RO200C-175
|
|
(A) 3,000
|
(B) 2,750
|
XW2Z-RO300C-275
|
|
(A) 5,000
|
(B) 4,750
|
XW2Z-RO500C-475
|
|
Cables with Connectors (1:3)
XW2Z-R_C-_-_
|
48 I/O points
|
|
(A) 1,500
|
(B) 1,250
|
(C) 1,000
|
PLC I/O Units with
Fujitsu connectors (1:3)
|
XW2Z-R150C-125-100
|
|
(A) 2,000
|
(B) 1,750
|
(C) 1,500
|
XW2Z-R200C-175-150
|
|
(A) 3,000
|
(B) 2,750
|
(C) 2,500
|
XW2Z-R300C-275-250
|
|
Cables with Connectors (1:1)
XW2Z-RI_C,
XW2Z-RO_C
|
16 input points
|
|
250
|
PLC I/O Units with
MIL connectors (1:1)
|
XW2Z-RI25C
|
|
500
|
XW2Z-RI50C
|
|
16 output points
|
250
|
XW2Z-RO25C
|
|
500
|
XW2Z-RO50C
|
|
Cables with Connectors (1:2)
XW2Z-RI_-_-D1, XW2Z-RO_-_-D1, XW2Z-RM_-_-D1, XW2Z-RI_-_-D2, XW2Z-RM_-_-D2
|
32 input points
|
|
(A) 500
|
(B) 250
|
PLC I/O Units with
MIL connectors (NPN) (1:2)
|
XW2Z-RI50-25-D1
|
|
(A) 750
|
(B) 500
|
XW2Z-RI75-50-D1
|
|
32 output points
|
(A) 500
|
(B) 250
|
XW2Z-RO50-25-D1
|
|
(A) 750
|
(B) 500
|
XW2Z-RO75-50-D1
|
|
16 input points/
16 output points
|
(A) 500
|
(B) 250
|
XW2Z-RM50-25-D1
|
|
(A) 750
|
(B) 500
|
XW2Z-RM75-50-D1
|
|
32 input points
|
(A) 500
|
(B) 250
|
PLC I/O Units with
MIL connectors (PNP) (1:2)
|
XW2Z-RI50-25-D2
|
|
(A) 750
|
(B) 500
|
XW2Z-RI75-50-D2
|
|
16 input points/
16 output points
|
(A) 500
|
(B) 250
|
XW2Z-RM50-25-D2
|
|
(A) 750
|
(B) 500
|
XW2Z-RM75-50-D2
|
|
Mitsubishi Electric
PLC Connecting Cables
XW2Z-RI_C-_-MN, XW2Z-RO_C-_-MN
|
32 input points
|
|
(A) 1,000
|
(B) 750
|
Mitsubishi Electric PLCs with 32-point connectors (1:2)
For inputs:
AX42, A1SX41, A1SX42
For outputs:
AY42, A1SY41, A1SY42
|
XW2Z-RI100C-75-MN
|
|
(A) 1,500
|
(B) 1,250
|
XW2Z-RI150C-125-MN
|
|
(A) 2,000
|
(B) 1,750
|
XW2Z-RI200C-175-MN
|
|
(A) 3,000
|
(B) 2,750
|
XW2Z-RI300C-275-MN
|
|
32 output points
|
(A) 1,000
|
(B) 750
|
XW2Z-RO100C-75-MN
|
|
(A) 1,500
|
(B) 1,250
|
XW2Z-RO150C-125-MN
|
|
(A) 2,000
|
(B) 1,500
|
XW2Z-RO200C-150-MN
|
|
(A) 2,000
|
(B) 1,750
|
XW2Z-RO200C-175-MN
|
|
(A) 3,000
|
(B) 2,750
|
XW2Z-RO300C-275-MN
|
|
Schneider Electric
PLC Connecting Cables
XW2Z-R_C-SCH-_
|
32 input points
|
|
500
|
Schneider Electric PLCs with 32-point connectors (1:2)
For inputs:
140 DDI 353 00
For outputs:
140 DDO 353 00
|
XW2Z-R050C-SCH-A
|
|
1,000
|
XW2Z-R100C-SCH-A
|
|
2,000
|
XW2Z-R200C-SCH-A
|
|
3,000
|
XW2Z-R300C-SCH-A
|
|
5,000
|
XW2Z-R500C-SCH-A
|
|
32 output points
|
500
|
XW2Z-R050C-SCH-B
|
|
1,000
|
XW2Z-R100C-SCH-B
|
|
2,000
|
XW2Z-R200C-SCH-B
|
|
3,000
|
XW2Z-R300C-SCH-B
|
|
5,000
|
XW2Z-R500C-SCH-B
|
|
16 input points
|
|
500
|
Schneider Electric PLCs with 16-point connectors (1:1)
For inputs:
BMX DDI 1602
For outputs:
BMX DDO 1602
|
XW2Z-R050C-SCH-C
|
|
1,000
|
XW2Z-R100C-SCH-C
|
|
2,000
|
XW2Z-R200C-SCH-C
|
|
3,000
|
XW2Z-R300C-SCH-C
|
|
5,000
|
XW2Z-R500C-SCH-C
|
|
16 output points
|
500
|
XW2Z-R050C-SCH-D
|
|
1,000
|
XW2Z-R100C-SCH-D
|
|
2,000
|
XW2Z-R200C-SCH-D
|
|
3,000
|
XW2Z-R300C-SCH-D
|
|
5,000
|
XW2Z-R500C-SCH-D
|
|
Siemens
PLC Connecting Cables
XW2Z-R_C-SIM-_
|
32 input points
|
|
500
|
Siemens PLCs with
32-point connectors (1:2)
For inputs:
6ES7 321-1BL00-0AA0
For outputs:
6ES7 322-1BL00-0AA0
|
XW2Z-R050C-SIM-A
|
|
1,000
|
XW2Z-R100C-SIM-A
|
|
2,000
|
XW2Z-R200C-SIM-A
|
|
3,000
|
XW2Z-R300C-SIM-A
|
|
5,000
|
XW2Z-R500C-SIM-A
|
|
32 output points
|
500
|
XW2Z-R050C-SIM-B
|
|
1,000
|
XW2Z-R100C-SIM-B
|
|
2,000
|
XW2Z-R200C-SIM-B
|
|
3,000
|
XW2Z-R300C-SIM-B
|
|
5,000
|
XW2Z-R500C-SIM-B
|
|
16 input points
|
|
500
|
Siemens PLCs with
16-point connectors (1:1)
For inputs:
6ES7 321-1BH02-0AA0
|
XW2Z-R050C-SIM-C
|
|
1,000
|
XW2Z-R100C-SIM-C
|
|
2,000
|
XW2Z-R200C-SIM-C
|
|
3,000
|
XW2Z-R300C-SIM-C
|
|
5,000
|
XW2Z-R500C-SIM-C
|
|
32 input points
|
|
500
|
Siemens PLCs with
32-point connectors (1:2)
For inputs:
6ES7 421-1BL-0AA0
For outputs:
6ES7 422-1BL-0AA0
|
XW2Z-R050C-SIM-D
|
|
1,000
|
XW2Z-R100C-SIM-D
|
|
2,000
|
XW2Z-R200C-SIM-D
|
|
3,000
|
XW2Z-R300C-SIM-D
|
|
5,000
|
XW2Z-R500C-SIM-D
|
|
32 output points
|
500
|
XW2Z-R050C-SIM-E
|
|
1,000
|
XW2Z-R100C-SIM-E
|
|
2,000
|
XW2Z-R200C-SIM-E
|
|
3,000
|
XW2Z-R300C-SIM-E
|
|
5,000
|
XW2Z-R500C-SIM-E
|
Further more information on the line-up and specifications of connecting cables, parts for DIN track mounting and labels, please enter “R242” in the search field on our website industrial.omron.eu
Specifications
|
Item
|
Model
|
G70V-SID16P(-1)
(Input, DC coil)
|
G70V-SOC16P(-1)
(output, DC coil)
|
|
Coil Ratings
|
Rated voltage (V)
|
24 VDC
|
|
Rated current (mA)
,
|
13.3
|
|
Coil resistance ( Ω )
|
1575
|
|
Must operate of rated voltage
|
80% max.
|
|
Must release of rated voltage
|
10% min.
|
|
Maximum voltage of rated voltage
|
110%
|
|
Power consumption (mW)
|
Approx. 280
|
|
Contact form
|
SPST-NO × 16
|
SPDT × 16
|
|
Contact material
|
Ag alloy + Au plating
|
Ag alloy
|
|
Contact resistance
|
150 m Ω max.
|
|
Must Operate time
|
20 ms max.
|
|
Release time
|
40 ms max.
|
|
Max. switching frequency
|
Mechanical limit
|
18,000 operations/hour
|
|
At rated load
|
1,800 operations/hr (under rated load)
|
|
Insulation resistance
|
100 m Ω max.
|
|
Dielectric strength
|
Between coil and contacts: 2,500 VAC for 1 min
|
|
Ambient operating temperature
|
− 40 to 55°C (with no icing or condensation)
|
|
LED color
|
Power supply
|
Green
|
|
I/O
|
Yellow
|
|
Size in mm (H × W × D)
|
90×143×56 (max.)
|
|
Weight
|
Approx. 350 g
|
Approx. 370 g
|
