Shielded

M8

3 mm

Pre-wired Models
(2 m)

Vinyl chloride (PVC)
(oil-resistant reinforced)

Yes

E2EQ-X3D18 2M

E2EQ-X3D28 2M

No

E2EQ-X3D18-T 2M

E2EQ-X3D28-T 2M

M12 Pre-wired Smartclick Connector Models (0.3 m)

Yes

E2EQ-X3D18-M1TGJ 0.3M

E2EQ-X3D28-M1TGJ 0.3M

No

E2EQ-X3D18-M1TGJ-T 0.3M

E2EQ-X3D28-M1TGJ-T 0.3M

M12

7 mm

Pre-wired Models
(2 m)

Yes

E2EQ-X7D112 2M

E2EQ-X7D212 2M

No

E2EQ-X7D112-T 2M

E2EQ-X7D212-T 2M

M12 Pre-wired Smartclick Connector Models (0.3 m)

Yes

E2EQ-X7D112-M1TGJ 0.3M

E2EQ-X7D212-M1TGJ 0.3M

No

E2EQ-X7D112-M1TGJ-T 0.3M

E2EQ-X7D212-M1TGJ-T 0.3M

M18

11 mm

Pre-wired Models
(2 m)

Yes

E2EQ-X11D118 2M

E2EQ-X11D218 2M

No

E2EQ-X11D118-T 2M

E2EQ-X11D218-T 2M

M12 Pre-wired Smartclick Connector Models (0.3 m)

Yes

E2EQ-X11D118-M1TGJ 0.3M

E2EQ-X11D218-M1TGJ 0.3M

No

E2EQ-X11D118-M1TGJ-T 0.3M

E2EQ-X11D218-M1TGJ-T 0.3M

M30

20 mm

Pre-wired Models
(2 m)

Yes

E2EQ-X20D130 2M

E2EQ-X20D230 2M

No

E2EQ-X20D130-T 2M

E2EQ-X20D230-T 2M

M12 Pre-wired Smartclick Connector Models (0.3 m)

Yes

E2EQ-X20D130-M1TGJ 0.3M

E2EQ-X20D230-M1TGJ 0.3M

No

E2EQ-X20D130-M1TGJ-T 0.3M

E2EQ-X20D230-M1TGJ-T 0.3M

M12 Straight, Smartclick Connectors

Sockets on One Cable End

6 dia.

1 m

E2E-X ⬜ D ⬜ -M1TGJ(-T)

E2EQ-X ⬜ D ⬜ -M1TGJ(-T)

XS5F-D421-C80-F

2 m

XS5F-D421-D80-F

3 m

XS5F-D421-E80-F

5 m

XS5F-D421-G80-F

10 m

XS5F-D421-J80-F

Socket and Plug on Cable Ends

1 m

XS5W-D421-C81-F

2 m

XS5W-D421-D81-F

3 m

XS5W-D421-E81-F

5 m

XS5W-D421-G81-F

10 m

XS5W-D421-J81-F

E2E NEXT M8 Shielded Sensors

1

Y92E-J8S12

E2E NEXT M12 Shielded Sensors

1

Y92E-J12S18

E2E NEXT M18 Shielded Sensors

1

Y92E-J18S30

Sensing distance

3 mm ±10%

7 mm ±10%

11 mm ±10%

20 mm ±10%

Setting distance

0 to 2.4 mm

0 to 5.6 mm

0 to 8.8 mm

0 to 16 mm

Differential travel

15% max. of sensing distance

Detectable object

Ferrous metal (The sensing distance decreases with non-ferrous metal.)

Standard sensing object

Iron, 9 × 9 × 1 mm

Iron, 21 × 21 × 1 mm

Iron, 33 × 33 × 1 mm

Iron, 60 × 60 × 1 mm

Response frequency

1,000 Hz

800 Hz

500 Hz

200 Hz

Power supply voltage

10 to 30 VDC, (including 10% ripple (p-p))

Leakage current

0.8 mA max.

Control output

Load current

3 to 100 mA

Residual voltage

Polarity: 3 V max. (Load current: 100 mA, Cable length: 2 m)

No polarity: 5 V max. (Load current: 100 mA, Cable length: 2 m)

Indicator

D1 Models: Operation indicator (orange), Setting indicator (green)

D2 Models: Operation indicator (orange)

Operation mode

D1 Models: NO

D2 Models: NC

Protection circuits

Surge suppressor, Load short-circuit protection

Ambient temperature range

Operating: -25 to 70°C, Storage: -40 to 85°C (with no icing or condensation)

Ambient humidity range

Operating and Storage: 35% to 95% (with no condensation)

Temperature influence

±10% max. of sensing distance at 23°C
in the temperature range of -25 to 70°C

±20% max. of sensing distance at 23°C
in the temperature range of -25 to 70°C

Voltage influence

±1% max. of sensing distance at rated voltage in the rated voltage ±15% range

Insulation resistance

50 MΩ min. (at 500 VDC) between current-carrying parts and case

Dielectric strength

1,000 VAC, 50/60 Hz for 1 minute between current-carrying parts and case

Vibration resistance (destruction)

10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions

Shock resistance (destruction)

500 m/s ² 10 times each in X, Y, and Z directions

1,000 m/s ² 10 times each in X, Y, and Z directions

Degree of protection

Pre-wired Models/Pre-wired Connector Models: IP67 (IEC 60529) and IP67G

(JIS C 0920 Annex 1)

Connecting method

Pre-wired Models (Standard cable length: 2 m) and Pre-wired Connector Models (Standard cable length: 0.3 m)

Weight

(packed state)

Pre-wired Models

Approx. 60 g

Approx. 70 g

Approx. 150 g

Approx. 210 g

Pre-wired Connector Models

Approx. 30 g

Approx. 40 g

Approx. 90 g

Approx. 140 g

Materials

Case

Fluororesin coating (Base material: brass)

Sensing surface

Fluororesin

Clamping nuts

Fluororesin coating (Base material: brass)

Toothed washer

Zinc-plated iron

Cable

Vinyl chloride (PVC)

Accessories

Instruction manual, Clamping nuts, Toothed washer

Rated current

4 A

Rated voltage

250 VDC

Contact resistance (connector)

40 mΩ max. (20 mV max., 100 mA max.)

Insulation resistance

1,000 MΩ min. (at 500 VDC)

Dielectric strength (connector)

1,500 VAC for 1 min (leakage current: 1 mA max.)

Degree of protection

IP67 (IEC60529)

Insertion tolerance

50 times min.

Lock strength

Tensile: 100 N/15 s, Torsion: 1 N·m/15 s

Cable holding strength

Tensile: 100 N/15 s, Torsion: 1 N·m/15 s (for cable diameter of 6 mm)

Lock operating force

0.1 to 0.25 N·m

Ambient operating temperature range

−25 to 70°C

Ambient humidity range

20% to 85%

Number of pressure-weld repairs

10 times max. (Limited to the same external diameter and wire diameter.)
