Omron D40A/G9SX-NS; Elektronik kontaksız kapı izleme sistemi

Omron D40A/G9SX-NS; Yavaş çalışan kapıları ile uygulama güvenliğinde sınıfının en iyisi olup, G9SX-NS kontrol ünitesine 30 adet D40A kontaksız switch bağlanabilmesi özelliği ile uygulamada esneklik sunar.

Kararlı çalıştırma, kararsız kapılardan kaynaklanan kontrolör hatalarını azaltır
30 adede kadar LED’li kontaksız kapı switch’ini bir kontrolöre bağlayın
Döndürülebilir switch kurulumda esneklik sağlar
Kolay bakım için iki renkli LED indikatör

Diğer emniyet kapı switchleri için tıklayınız.

Ürün broşürleri

Özellikler ve sipariş bilgisi

Ordering information

Non-contact door switches (switch/actuator)

Classification	Auxiliary outputs	Cable length	Order code
Standard models	Semiconductor outputs 1	2 m	D40A-1C2
		5 m	D40A-1C5
		Pigtail with M12 connector 4-pole	D40A-1C015-F

Non-contact door switch controllers (Controllers for D40A)

Safety outputs 2		Auxiliary outputs 3	Logical AND connection input	Logical AND connection output	Max. OFF delay time 4	Rated voltage	Terminal block type	Order code
Instantaneous	OFF-delayed 5	Auxiliary outputs 3	Logical AND connection input	Logical AND connection output	Max. OFF delay time 4	Rated voltage	Terminal block type	Order code
2 (Semi- conductors)	0	2 (Semi-conductors)	1	1	−	24 VDC	Screw terminals	G9SX-NS202-RT
	0				−		Spring-cage terminals	G9SX-NS202-RC
	2 (Semi- conductors)				3.0 s		Screw terminals	G9SX-NSA222-T03-RT
	2 (Semi- conductors)				3.0 s		Spring-cage terminals	G9SX-NSA222-T03-RC

Specifications

Ratings/characteristics of non-contact door switches

Item	Model	D40A-1C_
Operating characteristics 6	Operating distance OFF ® ON	5 mm min.
	Operating distance ON ® OFF	15 mm max.
	Differential travel (max.)	20% of operating distance
Ambient operating temperature		−10 to 55°C (no icing or condensation)
Vibration resistance		10 to 55 to 10 Hz (single amplitude: 0.75 mm, double amplitude: 1.5 mm)
Shock resistance		300 m/s 2 min.
Degree of protection		IP67
Material		PBT resin
Mounting method		M4 screws
Power consumption		0.6 W max.
Auxiliary outputs 7		24 VDC, 10 mA (PNP open-collector outputs)
LED indicators		Actuator not detected (red); actuator detected (yellow)
Connection cables		2 m, 5 m
Number of connectable switches		30 max. (wiring length: 100 m max.)

Ratings of non-contact door switch controllers

Power input

Item		G9SX-NS202-_	G9SX-NSA222-T03-_	G9SX-EX-_
Rated supply voltage		24 VDC

Inputs

Item		G9SX-NS202-_/G9SX-NSA222-T03-_
Safety input 8		Operating voltage: 20.4 VDC to 26.4 VDC, internal impedance: approx. 2.8 k Ω
Feedback/reset input

Outputs

Item	G9SX-NS202-_/G9SX-NSA222-T03-_
Instantaneous safety output OFF-delayed safety output	P channel MOS FET transistor output Load current: 0.8 A DC max.
Auxiliary output	PNP transistor output Load current: 100 mA max.

Item

G9SX-NS202-_/G9SX-NSA222-T03-_

Instantaneous safety output
OFF-delayed safety output

P channel MOS FET transistor output

Load current: 0.8 A DC max.

Auxiliary output

PNP transistor output

Load current: 100 mA max.

Non-contact door switch and non-contact door switch controller wiring

Example: Wiring a single switch

Note: The auxiliary output load current must be 10 mA max.

Example: Wiring multiple switches
Connect up to 30 Non-contact door switches

Note: Must be used in combination with a G9SX-NS_ non-contact door switch controller.

Omron D40A/G9SX-NS
